ADS-B UPDATE 2023 – WHERE ARE WE NOW?
The following is an overview of what ADS-B is, which countries already require ADS-B, and those who have upcoming mandates:
ADS-B is now required when operating overall 48 continuous states, within airspace at or above FL 100 (excluding airspace from 2,500 ft. AGL). At or below FL100 ADS-B will be required:
- While operating within class B or C airspace.
- While operating within 12NM of the coastline in the Gulf of Mexico, at or above 3,000 ft. MSL.
Requirements for Alaska, Hawaii, Puerto Rico, and the U.S. Virgin Islands are slightly different. The class E requirement does not apply to these areas. ADS-B will be required at or above FL180 and at or below FL100, you will need it when:
- While operating within class B or C airspace.
- While operating within 12NM of the coastline.
For the Guam and Northern Mariana Islands (South of 1749N), the only requirements are at or above FL180 and while operating within 12NM of the coastline.
Currently there are no ADS-B requirements for Navassa Island, American Samoa, Baker Island, Howland Island, Jarvis Island, Johnston Atoll, Kingman Reef, Midway Atoll, Northern Mariana Islands (North of 1749N), Palmyra Atoll and Wake Atoll.
ADS-B is required when operating over the U.S. as of Jan. 1, 2020. However, aircraft without the necessary ADS-B capabilities can still operate in U.S. airspace with a single-use route deviation authorization obtained through the FAA’s ADS-B Deviation Authorization Pre-Flight Tool (ADAPT).
To accommodate requests for authorization to deviate from this rule, the web-based tool known as ADAPT was created. As stated in an FAA policy statement (84 Federal Register 12062 dated April 1, 2019), ADAPT is not intended to be used for regular or routine operations by non-equipped aircraft, and your use of ADAPT appears to be regular and/or routine.).
Suppose the FAA denies your requests due to regular and/or routine use. In that case, a one-time authorization may be requested for actual ADS-B equipment installation or ferry of aircraft.
- Applies to U.S. airspace route segments only
- Only valid for a single route
- Applications can be submitted 24 hrs. to 1 hr. in advance of departure
- Authorizations are only valid within a +2 hour window of approved ETD
Universal is now supporting operators with turnkey FAA ADAPT ADS-B Exemption support. For more information on this service, contact our Global Regulatory Services Team.
ADS-B is required for all IFR operations at all flight levels over continental Australia, the Arafura Sea (bounded on the north by airway B598), the Great Australian Bight (bounded on the south by airway Q27/L513), and the Bass Strait (bounded on the east by airway H20 and to the southwest by L513). More information can be found on AIP GEN 1.5, ENR 1 | CASA 61/14
ADS-B is mandated for all aircraft. Requirements apply only to instrument flight rule (IFR) flights and only for aircraft with a maximum takeoff weight (MTOW) of 5700 kg (12,566 lbs.) or greater and/or max cruising true airspeed (TAS) greater than 250 knots (kts).
The transitional phase will end this year on June 7th, 2023. Up until this date, an aircraft can be exempt from the mandate based on one of the following.
- The first individual Certificate of Airworthiness was issued on or after June 7th, 1995 and before December 7th, 2020 and
- The operator has established a retrofit program prior to December 7th, 2020 that demonstrates compliance prior to June 7th, 2023 (Reference EU No 1207/2011, Article 5, part (c)) and
- The aircraft has not benefited from EU funding for the retrofit implementation (Reference EU No 1207/2011, Article 5, part (c)).
An aircraft will be exempt from the mandate if they meet one of these criteria.
- Individual Certificate of Airworthiness first issued before June 7th, 1995, OR
- Flight purpose is for maintenance or export, OR
- Operation will cease by 31-OCT-2025
If an aircraft meets any of the exemptions above, enter EUADSBX into the Item 18 SUR/ field of their FPL.
ADS-B is required for all operations above FL285. For more information, see AIP GEN 1.5 and ENR 1.10.
ADS-B is required for all flights within Jakarta (WIIF) and Ujung Pandang (WAAF) flight information regions (FIRs) at and above FL245. Below FL245 ADS-B is required in multiple TMA and CTR airspace as well as parts of Class D and E airspace. More information can be found at AIP ENR 1.6.
The initial mandate that was supposed to go into effect on June 7th, 2020, has been delayed indefinitely per AIC 10/20. Based on AIC 01/19, the mandate that is to be applied sometime in the future is as follows: All flights within the Seychelles (FSSS) FIR require ADS-B. Some automatic exemptions are available such as; STATE aircraft, small aircraft, and others. See AIC 01/19 and AIC 10/20 for more information.
ADS-B is required for all operations at or above FL290 within the area bounded by:
073605N 1090045E, 040713N 1063543E, 041717N 1061247E (MABLI), 044841N 1052247E (DOLOX), 045224N 1041442E (ENREP), 045000N 1034400E, thence north along the Singapore FIR boundary to 070000N 1080000E
This area includes the following airways: L517, L625, L642, L644, L649, M753, M758, M767, M768, M771, M772, M904, N884, N891, N892, Q801, Q802, Q803, and T611.
For more information, see AIC 03/20.
ADS-B is required within a prescribed area (See AIP SUP 02/20 for more details).
Aircraft manufactured before 01-JAN-2020 must have ADS-B (Out) 1090 MHz applicable to RTCA DO-260, DO-260A, or DO-260B. Aircraft manufactured on or after 01-JAN-2020 and has an MTOW exceeding 12,566 lbs (5,700 kgs) or having a maximum cruising true airspeed (TAS) greater than 250 knots must have ADS-B (Out) 1090 MHz applicable to RTCA DO-260B.
For more information, see AIP ENR 1.6.3.
Currently, ADS-B is required for all flights at or above FL290 within the VVHM FIR whose MTOW is 5,700 kgs (12,566 lbs) or heavier. All flights operating along airways L625, L628, L642, M765. M768, M771, N500, and N892 require ADS-B at or above FL290.
ADS-B is mandatory for all aircraft operating within the Taipei FIR, at or above FL290. For more information, see ENR 1.8.13.
ADS-B is currently required for all flights at and above FL290 if operating in one of the following Urumqi CTA sectors. ZWWWAR02, ZWWWAR03, ZWWWAR05 and ZWWWAR06. For more information, see AIP SUP 08/18.
ADS-B is required for all flights within Colombia airspace, at all flight levels. For more information, see RAC 4 22.214.171.124.
The current requirement is for aircraft to be ADS-B equipped to operate at or above FL285 on ATS routes in Indian continental airspace with designators L, M, N, P, Q, T and routes A201, A347, A465, A474, A791, B211, B466, G450, R457, R460, R461, W15, W19, W20, W29, W41, W43, W45, W47, W56S/N, W67, W111, W112, W114, W115, W118, W153. For more information, see AIP SUP 148/18.
In 2022 Malaysia canceled its original plans to require ADS-B throughout the WMFC and WBFC FIRs. As of now, they are only running trials and there are no mandates planned until 2025. However, if operating within the Oceanic airspace of WMFC they do note: not be accorded priority in the delineated airspace and flight level assignments will be on opportunity basis subject to air traffic conditions (ENR 1.1, paragraph 126.96.36.199.2)
For more information: ENR 1.1, paragraph 1.1.15 and AIC 03/17
Currently, all flights operating within New Zealand where at or above FL245 where Transponder Mandatory Controlled Airspace exists require ADS-B. A second phase to begin on December 31st, 2022, will extend this requirement all the way to the surface. More information may be found at https://www.nss.govt.nz/ads-b
French Polynesia / Tahiti (NTTT) FIR
ADS-B is required for all flights in the NTTT FIR since January 1, 2022. More information is located at AIP ENR 1.6.3.
As per U.A.E. AIP GEN 1.5 and CAR Part IV Aircraft Operations, CAR OPS 1.867 ADS-B is mandated in the Emirates FIR for all IFR aircraft.
As per GACAR 91.477 (b)(1)(vi) ADS- B will be mandated starting on January 1st, 2023, in class A, E, and B/C/D (around major airports).
As of this writing South Africa has yet to set an implementation date for their ADS-B mandate.
ADS-B is mandated for all Mexican airspace IFR operations as of January 1, 2022. This does not apply to Mazatlán Oceanic (MMFO). More information at AIC 04/20.
As per AIC 10/19, all flights operating at and above FL290 requires ADS-B. On January 01, 2023, this requirement will extend all the way to the surface.
As per ENR 1.6, all flights operating at and above FL290 (8840 meters) requires ADS-B.
New Caledonia / NFFF FIR
All flights operating within the New Caledonia sector of the Nandi (NFFF) FIR requires ADS-B. For more information, see AIP PAC-N GEN 1.5.
Fiji / NFFF FIR
Effective 13-JUL-2023, all flights operating within the Fiji Domestic sector of the Nandi (NFFF) FIR requires ADS-B. For more information, see AIC 03/23.
Starting on June 24, 2022, all flights operating over the landmass of Guatemala will require ADS-B. For more information, see AIC 10/21.
Starting on June 24, 2022, all flights operating over the landmass of El Salvador will require ADS-B. For more information, see AIC 81/22.
All mandates in effect currently require your ADS-B equipment to meet the requirements for 1090ES (1090 MHz), while some areas (USA) also allow 978 UAT (978 MHz) equipment to be used. Be sure you have the correct version to operate where you are going.
Version FAA/RTCA Europe/EUROCAE
0 260 —
1 260A ED-102
2 260B ED-102A
3 260C ED-102B
Tips when traversing regions with ADS-B requirements
Become familiar with ICAO FPL equipment and capability codes (Items 10a/b and Item 18) as well as your performance-based navigation (PBN) codes to help prevent misunderstandings with air traffic control (ATC) while in flight. Know which codes apply to the specific operation. Remember that codes filed in the FPL should represent not only aircraft equipment and capabilities but also those crew members covered by necessary training, authorizations from state of registry, and working equipment.
Remember that even though some countries do not currently have any ADS-B mandates or any proposals for mandates, there is still quite a bit of ADS-B coverage out there. Those aircraft not equipped with ADS-B can still potentially run into situations as you are less equipped than those around you. Keep this mentality in mind while flying these days … “better equipped, better served,” as it is no longer just first come, first served.
